- 13.56 Mhz Mifare
- Backlit keyboard
- Indoor and outdoor
- Reading distance: up to 5 cm.
- Constructed of plastic
- 3 LED bulbs
- Color: Black
- Dimensions: 141 x 43 x 19 mm.
- This reader can handle 7 different UID standards, and also reads NFC UID.
- Integrated tamper switch (tamper)
- Low power consumption - up to 60% more energy efficient compared to other readers
- IP67 with Pigtail cable solution
- IP54 with Connector solution
- For larger orders, the reader and keyboard can be delivered in other colors
- For larger orders, it is possible to have your own logo applied
- Cable length of 600 cm.
NOTE.
OSDP card readers are available in 2 versions. A standard configuration for standard in-reader, and a version configured for out-reader functionality. If you need to use the out-reader function, please write this in the comments field when ordering.
- Buzzer
- Yes
- Display
- No
- Color
- Black
- IK class (Impact protection)
- 10
- IP class
- 67
- Cable connector
- Pigtail
- Cable length (cm)
- 600
- Communication protocol
- OSDP
- Reading technology
- Mifare
- Power source
- 9-30V
- Keypad
- 2x6 Touch
- Touchscreen
- No
- Manufacturer
- Idesco
